Built to work in very narrow aisles where other rolling ladders can’t
ProStep ultra-compact aluminum rolling ladders have a compact footprint and tight turning radius, opening up the spaces conventional rolling ladders can’t reach – built for warehouses, distribution centers, manufacturing, and MRO. They pair the industry’s largest published platform with an integrated handle that lifts the pivoting casters and locks the rubber-footed base – rolling to rock-solid in one motion.
- Compact. Maneuverable. Unstoppable.
Tight turning radius and compact footprint reach very narrow aisles, corners, and equipment other rolling ladders can’t. - More Room to Work
Large platforms and cantilever options extend reach over equipment and obstructions. - Rock-Solid Stability
Engage the handle — casters lift, rubber-footed base locks, platform stays put.
- OSHA + ANSI Compliant
Built to OSHA 29 CFR 1910.23(e) and ANSI A14.7 — the standards your facility is audited against. - Cost-Effective at Scale
In stock and fleet-priced — deploy across every aisle, bay, line, and MRO area. - Made in the USA
Engineered, manufactured, and supported domestically — shorter lead times, accountable quality.
Compliance Expert
A friendly expert is ready to discuss your project.
Nate Frank
Your friendly stair expert
PRODUCT INFO & SPECIFICATIONS
Technical specs, BIM/CAD Files, Specifications( CSI Spec), Elevation/Plan Views, Environmental/LEED/HPD
In a world dominated by welded, fixed-form units, Prostep takes steps in a new direction.
Compact footprint & tight turning radius
With a tight turning radius and compact footprint, access equipment, corners, and very narrow aisles that other rolling ladders can’t reach. Warehouse floor plans are aisle-constrained; conventional rolling ladders are built for wide-aisle forklift lanes and cannot physically maneuver in tighter classes.
Stability & safety interlock
Lift-and-Lock
The integrated handle lifts the pivoting casters and locks the rubber-footed base — rolling the ladder from rock-solid to rock-solid in one motion. The unit is secured to the floor by the base, not by locking casters. While the casters are lowered, making the unit mobile, the handle safely prevents the unit from being climbed.
CAPABILITY EXTENSION
INDUSTRY’S LARGEST WORK PLATFORM
Choose 6 or 9 sq. ft. of standard workspace, then add a 1′ or 2′ cantilever kit to expand the platform up to 15 sq. ft. and reach over equipment and obstructions.
The range
Two widths, fifteen configurations
Available in 2′ and 3′ widths from 40″ to 120″, with up to 9 sq ft of working platform. Optional 1′ and 2′ cantilever add-ons extend reach over conveyors, equipment, and obstructions where a standard platform won’t go. OSHA 29 CFR 1910.23(e) and ANSI A14.7 compliant.
2′ Wide Platform
6 SKUs · 40″–90″ · 6 sq ft platform
3′ Wide Platform
9 SKUs · 40″–120″ · 9 sq ft platform
Cantilever add-on
Reach over what’s in the way
An optional 1′ or 2′ cantilever extension spans obstructions and reaches over equipment, conveyor lines, or curved surfaces without compromising guardrail protection. Bolt-on and field-installable — reach over an obstruction from an aisle-friendly base position rather than repositioning a larger unit that can’t fit the aisle in the first place.
Dimensions
Specifications
All dimensions in inches; weight in pounds. Toggle platform width below.
2′ Wide Platform
| Model Steps | A Platform Height | B Overall Height | C Working Height | D Base Width | E Base Length | Turning Radius |
|---|---|---|---|---|---|---|
| PS-40 4 Steps | 40″ | 82.5″ | 106″ | 24″ | 67.5″ | 64″ |
| PS-50 5 Steps | 50″ | 92.5″ | 116″ | 24″ | 73.5″ | 70″ |
| PS-60 6 Steps | 60″ | 102.5″ | 126″ | 24″ | 79″ | 76″ |
| PS-70 7 Steps | 70″ | 112.5″ | 136″ | 24″ | 85″ | 81″ |
| PS-80 8 Steps | 80″ | 122.5″ | 146″ | 24″ | 90.5″ | 87″ |
| PS-90 9 Steps | 90″ | 132.5″ | 156″ | 24″ | 90.5″ | 93″ |
3′ Wide Platform
| Model Steps | A Platform Height | B Overall Height | C Working Height | D Base Width | E Base Length | Turning Radius |
|---|---|---|---|---|---|---|
| PS-40 4 Steps | 40″ | 82.5″ | 106″ | 36″ | 67.5″ | 64″ |
| PS-50 5 Steps | 50″ | 92.5″ | 116″ | 36″ | 73.5″ | 70″ |
| PS-60 6 Steps | 60″ | 102.5″ | 126″ | 36″ | 79″ | 76″ |
| PS-70 7 Steps | 70″ | 112.5″ | 136″ | 36″ | 85″ | 81″ |
| PS-80 8 Steps | 80″ | 122.5″ | 146″ | 36″ | 90.5″ | 87″ |
| PS-90 9 Steps | 90″ | 132.5″ | 156″ | 36″ | 90.5″ | 93″ |
| PS-100 10 Steps | 100″ | 142.5″ | 166″ | 36″ | 102″ | 99″ |
| PS-110 11 Steps | 110″ | 152.5″ | 176″ | 36″ | 108″ | 104″ |
| PS-120 12 Steps | 120″ | 162.5″ | 186″ | 36″ | 114″ | 110″ |
Aisle-fit finder
Find your size
No guessing whether the unit will physically fit.
| Model | HeightPlatform | 360°Turning radius | VNA Very Narrow Aisle 5–6 ft |
Narrow Aisle8–10 ft | Wide Aisle11–13 ft |
|---|---|---|---|---|---|
 PS-40 | 40″ | 64″ (5.3 ft) | ✓ | ✓ | ✓ |
 PS-50 | 50″ | 70″ (5.8 ft) | ~ | ✓ | ✓ |
 PS-60 | 60″ | 76″ (6.3 ft) | — | ✓ | ✓ |
 PS-70 | 70″ | 81″ (6.8 ft) | — | ✓ | ✓ |
 PS-80 | 80″ | 87″ (7.3 ft) | — | ✓ | ✓ |
 PS-90 | 90″ | 93″ (7.7 ft) | — | ✓ | ✓ |
 PS-100 | 100″ | 99″ (8.2 ft) | — | ~ | ✓ |
 PS-110 | 110″ | 104″ (8.7 ft) | — | ~ | ✓ |
 PS-120 | 120″ | 110″ (9.1 ft) | — | ~ | ✓ |
Questions
FAQ
Frequently Asked Questions
What is ProStep?
ProStep is an ultra-duty aluminum rolling ladder built for tight aisles. Nine platform heights are offered — PS-40 through PS-120, in 10-inch increments from 40 in. to 120 in. — with 2-ft or 3-ft platform widths and a bolt-on cantilever kit for reaching over obstructions. The system replaces the RFQ-only mobile platforms that warehouses and data centers have historically had to custom-order for tight-aisle work.
No. When the Lift-and-Lock handle is engaged, the casters lift roughly two inches off the floor and the rubber-footed base plants on the ground. The ladder is fully supported by the base, not the wheels, while a worker is on the platform. About 30 pounds of pull on the handle releases the largest unit for repositioning.
No. A caster lock is not required because the Lift-and-Lock base creates enough friction with its rubber pads that the unit stays planted under load. The friction pads carry the operator’s weight, not the casters.
Yes. ProStep is a four-caster rolling ladder with the Lift-and-Lock base. The design lets one person move a large unit without lifting an end of it — the older two-wheel tilt-and-roll pattern limited how large a rolling ladder could practically be.
Every ProStep model is rated for 1,000 lb, covering the operator plus tools and materials. The rating is consistent across all nine heights and both platform widths.
Two options: 6 sq ft (2-ft platform width) or 9 sq ft (3-ft platform width).
– Very narrow aisle (5–6 ft): PS-40 fits. PS-50 fits in most 6-ft aisles.
– Narrow aisle (8–10 ft): PS-40 through PS-90 fit. PS-100 and PS-110 fit tighter narrow aisles with clearance planning.
– Wide aisle (11–13 ft and up): All nine models fit.
Verify aisle width against the model’s 360° turning radius before ordering.
ProStep is engineered to OSHA 29 CFR 1910.23(e) for mobile ladder stands and platforms and to ANSI A14.7. Compliance documentation is available from your Regional Account Manager for engineering review or specification packages.
Yes. ProStep is manufactured in the USA at the SixAxis facility in South Carolina.
ProStep is bolt-together aluminum. The frame, platform, steps, and cantilever kits are all aluminum for corrosion resistance and lighter deadweight than similar steel units.
ProStep ships flat-packed and bolts together in the field. Standard hand tools complete the assembly. Cantilever kits attach to a fully assembled base without disassembling the ladder.
Yes. Bolt-together construction lets a facility swap a cantilever kit, change platform width, or replace individual components without discarding the ladder. Field-replaceable parts are stocked.
ProStep is sold through our authorized distributor network. Regional Account Managers qualify the request, size the correct model for the aisle, and route the order to a distributor for quoting, delivery, and post-install support. Contact ErectaStep at 843-485-0065 to be connected to the right distributor for your location.
The cantilever kit extends the working reach past the platform edge — 1 ft or 2 ft — so workers can access conveyors, racking, or equipment they cannot roll the ladder underneath. Kits bolt on and are field-installable.
Yes. Every model ships with the guardrail system required for OSHA 29 CFR 1910.23(e) and ANSI A14.7 compliance, including handrails, midrails, and toeboards on the top platform.
